- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.com
- Brand Name
- Supermicro
- Product Line
- SuperServer
- Product Type
- Server Barebone System
Designed for optimal performance, the dual-processor SuperServer 6036T-TF Barebone System supports the QPI format quad-core/dual-core Xeon processors in a high-density 3U form-factor. This 6026 SuperServer is ideal for network infrastructure, front-end enterprise and minimal-downtime cluster server systems.
- Warranty
- Limited Warranty
- 3 Year
- Processor
- Number of Processors Supported
- 2
- Processor Socket
- Socket B LGA-1366
- Processor Supported
- Xeon
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- 5520
- Memory
- Maximum Memory Supported
- 192 GB
- Memory Technology
- DDR3 SDRAM
- Memory Standard
- DDR3-1066/PC3-8500
- Total Number of Memory Slots
- 12
- Controllers
- Controller Type
- Serial ATA/300
- RAID Supported
- Yes
- Display & Graphics
- Graphics Controller Model
- G200eW
- Graphics Memory Capacity
- 16 MB
- Graphics Memory Technology
- DDR2 SDRAM
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 11
- Number of External 5.25" Bays
- 2
- Number of 3.5" Bays
- 1
- Total Number of Expansion Slots
- 6
- Number of PCI Express x4 Slots
- 2
- Number of PCI Express x8 Slots
- 4
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 4
- Network (RJ-45)
- Yes
- VGA
- Yes
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Number of Power Supplies Installed
- 1
- Maximum Power Supply Wattage
- 650 W
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Rack-mountable
- Rack Height
- 3U
- Height
- 7"
- Width
- 17.2"
- Depth
- 25.5"
- Miscellaneous
- Package Contents
- SuperServer 6036T-TF Barebone System
- 1 x Super X8DTE-F Motherboard
- 1 x 3U Chassis
- 1 x SAS833 BACK PANEL WITH AMI MG9072
- 2 x 61cm, SATA S-S, PBF
- 2 x 8pin to 8pin ribbon cable with tube for SGPIO, 40cm, PBF
- 4 x SATA CABLE 48CM FLAT S-S PBF
- 1 x CD For X8 series
- 2 x 2U+ PASSIVE CPU HS FOR INTEL LGA1366 X8 MB
- 1 x 2U 650W REDUNDANT FAN POWER SUPPLY
- 1 x Air Shroud (side Piece) for 3U Chassis
- 1 x SC833/933 Intel DP X8.X7 PC air shroud 12x13MB
- 4 x 4 TO 4 PIN MIDDLE FAN POWER EXTENSION, 200MM (PWM)
- 2 x 80x32 4 pin PWM fan assembly for SC832, 833, 835,836,933,936
- 4 x 92X38MM 4-PIN PWM FAN W/ HUS FOR SC833/933
- 8 x SCA TYPE ASSY (W/O LOGO)BLACK
- 1 x 3U CHASSIS RAIL. Outer slides extendable length: 28" to 33.67"
- Additional Information
QuickPath Technology:
- QuickPath Interconnect supports up to 6.4 GT/s
Storage Controller Detail:
- Serial ATA Controller supports RAID 0, 1, 10 for Linux
- Serial ATA Controller supports RAID 0, 1, 5, 10 for Windows
Drive Bays Detail:
- Supports up to 6 x SATA Hard Drives
- Environmentally Friendly
- Yes
