The SV831DVIU 8-Port 1U Rack Mount DVI USB KVM Switch lets you control up to 8 USB-connected computers (each with DVI or HDMI display output) from a single keyboard, mouse and monitor.
The KVM switch offers maximum control, allowing you to switch computers using hot-key commands or front panel push-buttons. Supporting digital resolutions up to 1920x1200 via DVI or HDMI connection (using DVI to HDMI adapter - see accessories), the KVM provides the high resolutions recommended for newer displays, allowing you to take full advantage of your monitor/screen capability.
A perfect addition to any server room or software test lab, this 8-port switch can be rack-mounted into 1U of cabinet space.
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
Note: This KVM supports digital signals only, and cannot be used with DVI-to-VGA adapters.
- General Information
- Manufacturer
- StarTech.com
- Manufacturer Website Address
- http://www.startech.com
- Brand Name
- StarTech.com
- Packaged Quantity
- 1
- Product Type
- KVM Switchbox
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Number of Computers Supported
- 8
- Video
- Graphic Mode
- WUXGA
- Maximum Video Resolution
- 1920 x 1200
- Interfaces/Ports
- USB
- Yes
- DVI
- Yes
- Number of USB Ports
- 10
- Number of DVI Ports
- 9
- Power Description
- Input Voltage
- 240 V AC
- Input Voltage Range
- 110V AC to 240V AC
- Physical Characteristics
- Product Color
- Black
- Form Factor
- Rack-mountable
- Rack Height
- 1U
- Height
- 1.7"
- Width
- 17.2"
- Depth
- 7.1"
- Weight (Approximate)
- 5.51 lb
- Miscellaneous
- Package Contents
- 8 Port 1U Rack Mount DVI USB KVM Switch
- 1 x Set Rack-Mount Brackets
- 3 x Power Cords (NA/EU/UK) or AU in Australia
- 1 x User Manual
- Environmentally Friendly
- Yes
- Country of Origin
- Taiwan
- TAA Compliant
- Yes
